10W 0-3000MHz Frequency 10W Coaxial Fixed 30dBi Female To Male Dc-6ghz Dc-3ghz Attenuator

This coaxial fixed attenuator is designed to handle up to 10 watts of power and operates effectively across a frequency range from direct current (DC) to 3000 megahertz (3 GHz). The attenuator features a female connector on one end and a male connector on the other, allowing it to be easily integrated into RF systems. It is commonly used in various RF applications to reduce signal strength and prevent distortion or overload.

• 10W: This indicates the maximum power handling capability of the attenuator, which is 10 watts. It means the attenuator can handle signals up to 10 watts without damage.

• 0-3000MHz: This is the frequency range over which the attenuator operates. In this case, it’s designed to work from 0 to 3000 megahertz (3 GHz). It’s worth noting that the attenuator is designed to work efficiently within this frequency range.

• 30dBi: This is likely a misunderstanding or typo, as 30 dBi refers to a gain measurement for antennas, not attenuators. For attenuators, you would typically see attenuation values like 10 dB, 20 dB, etc.

• Female to Male: This indicates the type of connectors on the attenuator. A female connector is one with a socket, and a male connector has pins that fit into a socket. This attenuator has one female and one male connector, allowing it to be connected between other male and female connectors.

• DC-6GHz / DC-3GHz: These frequencies indicate the operating range of the attenuator. DC (direct current) to 6 GHz or 3 GHz suggests the range of frequencies over which the attenuator is effective. You’ll want to confirm which frequency range is accurate for your specific needs.
